The Shop Wall Fastener Pack
10 large-print reference charts — the answers you Google mid-project, readable from across the shop. Print at home, hang them up, get back to building.
Get the pack — instant download
Instant download: one combined 13-page PDF plus all 10 charts as individual one-page PDFs. 100% vector text — sharp at any size, even poster-size at a print shop.
Digital download — nothing ships. Personal + single-shop license.
What's inside
- Screw Size Chart — gauge to inches & millimeters
- Pilot Hole Size Chart — hardwood & softwood
- Drill Bit Size for Screws — pilot & clearance holes
- Nail Penny Size Chart — pack exclusive, not on this site
- Drywall Anchor Weight Ratings — pick the right anchor
- Bolt Torque Chart — Grade 2 vs 5 vs 8
- Fraction to Decimal to Millimeters — pack exclusive, not on this site
- Nail & Screw Strength Chart — shear & pullout values (NDS 2024)
- Metric to Inch Bolt Conversion — M6–M20 at a glance
- Tap Drill Size Chart — inch & metric taps
Why print it?
- Large print — read it from across the shop, no squinting
- High-contrast navy — easy on the eyes under shop lighting
- Vector PDF — blow any page up to poster size with zero blur
- Two exclusives — penny sizes + fraction conversions aren't on the site
How it works
- Check out securely
- Download instantly from your receipt email
- Print at "Actual size / 100%" on US Letter
- Hang & build
Questions
Is this a physical product?
No — a digital PDF download. Nothing ships; print at home or any print shop.
What size do the charts print?
US Letter (8.5×11 in). Vector text scales cleanly to poster sizes like 18×24 or 24×36 at a print shop.
Can I share the files with a friend?
The license covers you and your shop. Friends can grab their own copy — it keeps the 370+ free guides on this site running.
What if a file won't print?
Just reply to your receipt email and we'll make it right — broken files get fixed or refunded, no fuss.
